3026 4 WD TECHNICAL SPECIFICATIONS Engine Type Mitsubishi SL-VL2AAB000 MVS3L2 Emission Type EU STAGE V Aspiration Naturally Aspirated Displacement / Number of Cylinders (cm3 / units) 1319 / 3 Maximum Engine Power (kw / hp / rpm) 18.2/25/2500 Rated Engine Power (kw / hp / rpm) 18.2/25/2500 Maximum Engine Torque (nm / rpm) 76.3/2000 Air Filter Type 2 Stage Air Filter Injection System Water Cooled Fuel Tank (Lt) 25 TRANSMISSION Gearbox 9 + 3 Four-Wheel Drive Control Mechanical Rear Differential Lock Mechanical Hydraulic System Maximum Pump Flow Rate/Pump Pressure (L/min)/bar 100/200 Functions Mechanically Controlled Hydraulic Power Output output/valve 2/1 Lifting Capacity (kg) 800 PTO Type Independent Dual Speed PTO Speed (Engine Speed) (rpm) 540 - 540E BRAKES Type Oil Immersed Disc Brake Foot Brake Mechanically Controlled Parking Brake Mechanically Controlled TIRE OPTIONS (mm) 1st Option (Front) 6.00-12/8.3-20 WEIGHTS AND DIMENSIONS Front Weight kg 2 x 6 Tractor Weight kg 1055 Overall Length mm 2840 Wheelbase mm 1540 Overall Width mm 1200 Overall Height mm 2580 Front Track Width mm 865 -1000 Rear Track Width mm 960 -1100 Ground Clearance mm 320 EQUIPMENT Battery Disconnect Switch Standard 3026 Engine Power 25 HP Gear Option 9 Forward 3 Reverse Hydraulic Lifting Capacity 800 Kg Hydraulic Valve Output / PTO 2 Units / 540 - 540E
