Width: 1300 mm Length: 2500 mm Number of Cylinders: 6 units Pressing Power: 50 tons Opening Size: 400 mm Plate Type: MDF Frame (Chassis): Features a robust, white-painted steel construction to withstand heavy loads and pressure. Hydraulic Cylinders: Located at the bottom of the machine, there are 6 powerful hydraulic pistons (chrome-plated shafts) that apply pressure by pushing the upper platen upwards. Control Panel: The panel, located on the side, allows for machine operation with a pressure gauge (manometer), emergency stop button, and operational buttons. Motor and Hydraulic Unit: The electric motor, positioned on the right side, provides the necessary power to the hydraulic system. Rack and Pinion System: Vertical gear racks on both sides of the platen ensure the platen moves completely parallel during pressing and presses evenly. Purpose of Use These types of machines are generally used for the following processes: Lamination: Gluing veneer, laminate, or MDF onto wood panels. Panel Joining: Pressing multiple layers together under high pressure. Forming: Shaping material using specific molds. Technical Details The design shown, with its open structure, allows the operator to easily load and unload material from both sides. It is often preferred in door production, furniture panels, and flooring production lines.
$null
1. Working System (Copy Lathe) This machine operates on the "copy lathe" principle. Due to having multiple spindles (4 metal rods visible on the left in the photo), it can process 4 pieces simultaneously, making them identical. This significantly increases production speed and efficiency. 2. Technical Components Spindles: The horizontal spindles on the left are where the wooden parts are attached. The parts rotate at high speed here. CNC Control Panel: The touchscreen panel on the upper left allows for precise management of the machine's movements, speed, and cutter path. Sanding Unit: The belts inside (in the section we've removed) are used to smooth the surface of the wood after the turning process, without removing it from the machine. Protective Housing and Glass: The machine is enclosed in a cabinet to prevent dust emission and ensure operator safety. Large windows allow for monitoring the processing. 3. Applications Classic and modern furniture legs. Stair railing posts. Kitchenware (rolling pins, pestles, etc.). Sports equipment. This is a copy lathe machine that produces 4 products in a single operation. It works by pneumatically following a 3D template. It offers the most ideal solutions for producing items such as chair and furniture legs, paddles, hand tools, rifle stocks, hangers, sports equipment, musical instruments, etc.
$null
Product Features and Areas of Use Multi-Axis Structure (4 Axis): As indicated by the inscriptions on it, it has 4-axis movement capability. This means it can process complex shapes (e.g., curved table legs or figured wood parts) with high precision. Functional Diversity: This machine does not perform just one operation; it can perform the following according to the modes specified on it: Lathing: Shaping cylindrical parts. Router / Milling: Grooving, surface processing, and carving. Mortiser: Mortise (hole) drilling operations. Sanding: Smoothing the surface by sanding. Control Panel: Thanks to the integrated computer (CNC control unit) on the left side, designs are transferred from the digital environment, and the machine cuts automatically. Safety Cabinet: The machine is surrounded by metal cages and guards. This protects the operator from flying chips and ensures work safety by preventing intervention inside the machine during operation. What can be produced with this machine? It is an ideal professional solution, especially in furniture manufacturing, for producing chair and table legs, stair railings (newel posts), wooden columns, and decorative furniture panels.
$null
Product Description This machine is a compact workshop equipment used to bring lumber to the desired precise thickness and smooth its surfaces. Its lightweight and portable structure makes it ideal for use in both workshops and outdoor work areas such as construction sites. Key Features: Portability: Easily transportable and usable on a workbench thanks to its compact design and side handles. Precise Height Adjustment: The thickness of the wood to be processed can be adjusted millimeter by millimeter using the crank handle on the top. Foldable Tables: The infeed and outfeed tables can be folded to save storage space when not in use. Scale Indicator: A clear ruler on the front of the machine allows tracking of the depth of cut and workpiece thickness. Safety Switch: A protected on/off button that can be quickly turned off in emergencies.
