Designed to control your production quality, this machine checks the strength of the welded heads of irrigation pipes.
$null
Independent movement for each pallet with A.C. motor and vector drives (wear-prone transmission elements eliminated – minimum maintenance and high reliability) All pallets are in pulling mode and the rubber blocks on them are shaped to provide the widest contact surface with the pipe. Upper pulling pallets can be adjusted at an angle. Even with minimum pressure on the pallets, maximum pulling force is achieved with minimum pallet pressure due to the high contact available on the pallets.
$null
Our winders, suitable for all types of pipe production, allow for safe and high-quality winding with their ability to operate in series and be adjusted to the desired torque value. In HAYTEK winders, torque and speed settings, as well as values such as the diameter of the wound pipe, can be easily controlled with the PLC touch screen control unit.
$null
Automatic threading machines that can work in-line or off-line, suitable for PVC electrical, gas, and water pipes (can be used for single and double extrusion) External and internal threading (with chamfering) occurs on both sides simultaneously. Independent spindle motors are used for both threading units. Thread lengths are adjustable. Thread depths are adjustable. Clamping of pipes during the threading process is provided by the iris mechanism jaw system. High efficiency and thread precision. Settings can be made from the touch screen for all pipe diameters. Easy operation, effective working, minimum maintenance. Optional servo system. Pipe preparation and storage stands. Clean working area thanks to dust-sealed structure
$null
Designed to ensure production efficiency and continuity with uninterrupted and optimal costs, the BAG OPENING MACHINE has a loading capacity of up to 4 tons thanks to its chain conveyor belts. The cutting of raw material bags is performed by 20 HSS blades. Shaker arms ensure the complete emptying of the cut bags. It is possible to fill big bags with empty bags thanks to the pusher helical system. The Bag opening machine, with an hourly capacity of 18 TONS, is PLC controlled with a touchscreen. With the silo control system, you can transfer raw materials to your production silos according to your production quantity with only two operators. The complete emptying of bags provides significant savings for companies with high tonnage production capacity. It can be produced food-grade upon request.
$null
Material: Made of cast aluminum, providing high thermal conductivity and durability. Structure: Features a cylindrical body composed of two halves. This "split" (separable) design allows for easy removal of the molded part or clamping around a sleeve. Fasteners: Screw holes and a flanged structure are visible on the sides, used to secure the parts together. Lid and Outlets: The lid on the top has outlet nozzles, likely used for electrical connections or sensor inputs (thermocouple, etc.), and a ring (eyebolt) for easy carrying.
$null
Dosing Hoppers: Two large hoppers (bunkers) located at the top are units where material is stored and transferred downwards. Precision Weighing System: The platforms located directly below the hoppers are generally equipped with load cells; this ensures that the product is filled into bags at the determined weight. Pneumatic Control: Pneumatic pistons connected by blue hoses control the flap mechanisms that start and stop the material flow. Filling Spouts: The weighed product is transferred directly into the bags to be packaged (like the red and white bag seen on the right in the visual) through inclined metal pipes. Control Panel: Manual control of the machine is provided by the start/stop buttons (green and red) located on the white stand on the left.
$null
The mini bag opening machine is preferred by companies with limited production space. Its ergonomic and economical design makes it easily portable, which is one of its biggest advantages. Bags are completely cut from the sides by two cutting arms, allowing the bags to be emptied. The bag pusher system facilitates the transfer of empty bags. The optional dust filter system prevents the spread of harmful chemicals into the production area, ensuring occupational health and safety. Thanks to its dust-proof structure, employees can load sacks onto the conveyor belt without manual contact and open bags containing harmful chemicals. The mini bag opening machine, with its optional 304 grade chrome body, is suitable for use in the food industry due to its compliance with food regulations, and can provide significant profits to your company based on your production volume. Our machine, with an hourly capacity of 9 tons, can be operated with the help of just one operator by adding an automatic loading system.
$null
Material Composition: They are produced from alloy steel with high wear resistance or heat-treated steel (hardened to higher HRC values). Stainless steel may be preferred for some parts against corrosion. Precision Machining: The surfaces of the parts are machined with micron-level precision on CNC machines and have undergone grinding/polishing processes to minimize friction. Sealing and Lubrication Grooves: Circular grooves (groove slots) seen on cylindrical bodies are for the placement of sealing elements (O-ring, seal) or for the homogeneous distribution of hydraulic oil. Drain and Connection Holes: The side holes, more prominent in the second image, are designed for the discharge of pressurized fluid or for fixing the part to a mechanism with a pin.
